NJ2DG Central Jersey D-Star Group

Gateway Programming

The NJ2DG Repeater System has G2 Gateway Access. All users accessing onto the new G2 gateway system nationally will need to register ONLY ONCE. If you choose, you can complete your initial G2 registration through      the following link: https://rpt.nj2dg.org/Dstar.org

Once receiving an email confirmation confirming your registration then you must sign back in through the                  above link and you must complete the following steps after clicking the Personal Information tab

Each user must set the first line (# 1 of 8) to be able to use the Gateway.

1) Check the box next to number 1 to enable editing for the line
2) Put a SPACE in the box under "Initial"
3) Do NOT check the RPT box
4) Type your call sign in the pcname box in lower case
5) Click the Update button

You have now successfully completed the G2 gateway registration process.                                                Questions(?) -> please contact: Randy WA2RMZ at wa2rmz@nj2dg.org or Scott KB2EAR at kb2ear@nj2dg.org

Some systems listed as G2 gateways on https://rpt.nj2dg.org/Dstar.org webpage under GW Information tab             may not be fully connected to a repeater system.



Programming by use the of the D-Star Calculator                                                                                            http://www.dstarinfo.com/Calculator/DSTAR%20Web%20Calculator.aspx?Source=NJ2DG

Programming Examples

Zone Call Example -> NJ2DG 440 Repeater to K5TIT 440 Repeater through the Gateway

URCALL   =/K5TIT B  This URCALL entry indicates that you are calling to K5TIT 440 Repeater, please note the leading character is the / followed by the repeater call with the module B in the 8th character position.                                                                                                                                                   RPT1  …. =  NJ2DG  B  The B (440 Repeater) must be in the 8th character position                             RPT2       =  NJ2DG  G  The G (Gateway) must be in the 8th character position                                    MYCALL =  your call sign



Gateway Call to a Individual -> Last Heard on the Gateway

URCALL   = K7FAY  Finding where K7FAY was last heard and trust server will automatically route your gateway call to the last module that K7FAY was heard on.                                                                     RPT1  …. =  NJ2DG  B  The B (440 Repeater) must be in the 8th character position                                  RPT2       =  NJ2DG  G  The G (Gateway) must be in the 8th character position                                    MYCALL =  your call sign



Gateway Call to Linked Repeaters with D-Plus (441.650 is currently linked to other repeaters)

URCALL   = CQCQCQ                                                                                                                            RPT1  …. =  NJ2DG  B  The B (440 Repeater) must be in the 8th character position                             RPT2       =  NJ2DG  G  The G (Gateway) must be in the 8th character position                                    MYCALL =  your call sign



Hot Spot / Node Simplex or Repeater

URCALL   = CQCQCQ                                                                                                                            RPT1  …. =  None                                                                                                                                   RPT2       =  None                                                                                                                              MYCALL =  your call sign

D-Star Dashboard for Reflector 20                                         NJ2DG B and C are connected, see who else is connected.             http://ref020.dstargaterway.org

KI4SWY Callsign Query for Gateway Registered Callsigns   “This is small website interface that anybody can goto, and Query a callsign, and it will tell you which repeaters are they are registered on, and if they have any terminals registered”.                          http://query.ki4swy.org

Regional D-Star Net                    Weekly every Tuesday at 7:30pm

NJ2DG B 441.650 Martinsville
